Dust prevention of guide rail slider

1、接觸纖維板密封

1. Contact fiberboard seal

“自潤滑密封”在“控油聚合物殼體”中增加了2塊纖維板元件。主纖維板元件是用于配合并覆蓋軌道的軌跡槽。而附纖維板是用于擦試并覆蓋滑軌的其他表面。主軌道纖維板能確保在滑軌表面與負載滑塊鋼珠金屬面之間始終有一層保護隔膜。附纖維板向滑軌的其他表面提供了良好的潤滑油層。因此在標準運行方式下能保證的防護力和抗腐力。吸油纖維板除了能延長壽命之外，其配合”自潤滑密封”更主要的優點事實上是使滑塊達到免維護，除非是在十分惡劣的運行條件下才需要進一步的維護。

"Self lubricating seal" adds 2 fiberboard elements in "oil control polymer housing". The main fiberboard element is a track slot used to fit and cover the track. The attached fiberboard is used for wiping and covering other surfaces of the slide rail. The fiberboard of the main track can ensure that there is always a protective diaphragm between the surface of the slide rail and the metal surface of the steel ball of the load slide. The attached fiberboard provides a good lubricating oil layer to other surfaces of the slide rail. Therefore, the overall protection and corrosion resistance can be guaranteed under the standard operation mode. In addition to prolonging the service life, the main advantage of oil absorbing fiberboard in combination with "self lubricating seal" is to make the slider maintenance free, unless further maintenance is required under very bad operating conditions.

2、自潤滑密封

2. Self lubricating seal

“自潤滑密封”延長了線性導軌各方面的使用壽命。每套裝配在線性導軌端蓋中的緊密密封工具都是由三部分組成的。這樣能保證線性導軌系統所有表面的潤滑并提供長期免維護。“自潤滑密封”的大優點在于其結構精密，同時也能裝配于所有標準線性導軌上。

"Self lubricating seal" extends the service life of linear guide rail in all aspects. Each set of tight sealing tools assembled in the linear guide end cap is composed of three parts. This can ensure the lubrication of all surfaces of the linear guide rail system and provide long-term maintenance free. The major advantage of the "self lubricating seal" is its precision structure, and it can also be assembled on all standard linear guides.

導軌用于高精密設備，如果不慎被粉塵及其他異物進入，將導致導軌異常磨損,并縮短使用壽命，由此可見防塵措施的重要性，所以為了防止可能會有粉塵及其他異物進入時，有必要使用滿足使用合適的防塵設備對導軌防塵保護。

The guide rail is used for high-precision equipment. If it is accidentally entered by dust and other foreign matters, it will lead to abnormal wear of the guide rail and shorten its service life. This shows the importance of dust prevention measures. Therefore, in order to prevent dust and other foreign matters from entering, it is necessary to use appropriate dust prevention equipment to protect the guide rail from dust.
